90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg

China 90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg supplier
90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg supplier 90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg supplier 90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg supplier 90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg supplier

Large Image :  90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg

Product Details:

Place of Origin: SHANGHAI
Brand Name: POOYERT
Certification: ISO9001:2015
Model Number: BK-A

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wood pallet / container depends on quanity
Delivery Time: 10-20 days
Payment Terms: L/C, D/A, D/P, T/T, MoneyGram, Western Union
Supply Ability: 3000 pieces per month
Contact Now
Detailed Product Description
Product Name: Robot Platform Tracks Width: 60mm
Pitch: 13.01mm Link: 90
Length: 1170.9mm Weight: 1.6kg
Material: Rubber Warranty: 1 Year

60 x 13.01 x 90 width 60mm pitch length 13.01 and 90 links mini size robot rubber track with high traction



Size: Width60*Pitch13.01*Link90
Tread height: 8mm;

Inner tread height: 10mm;

Track body thickness:4mm;

Inner teeth width: 21mm;
Length and link can be adjustable

Application: Mainly used in robot and other model number can used in Snowblower/Snowmobile, Robot,

Wheelchair, (mini)Excavators, Track loaders, Pitch Paver, Agricultural Harvester, Dumpers...Etc.

Warranty of the rubber track: Guarantee one year under normal use

90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg



More size

90 Links Mini Rubber Tracks With High Traction 13.01mm Pitch Weight 1.6kg
Application and Features of the rubber track:

1. Suitable for the small stairs wheelchair.

2. Can load weight about 80-100KG

3. Length can be adjusted.

4. Sprocket is available.


Characteristics of rubber track:

1). Less damage to the ground surface

2). Low noise

3). High running speed

4). Less vibration;

5). Low ground contack specific pressure

6). High tractive force

7). Light weight

8). Easy to change


Quality Control for the Rubber track

1. Ex works Inspection

2. Products Audits/Examination(Strict inspection according to customer's request)

3. Production Procedure Audit/Examination(Entire Procedure Control)

4. Raw material Inspection/Examination; Purchased Parts Inspection(Including All Purchased Material)


Parameter


Model Size (width*pitch) Weight (kg)/Link Model Size (width*pitch) Weight (kg)/Link Model Size (width*pitch) Weight (kg)/Link
BMW-30 30*12.7 0.00357 BD-B 100*40 0.0454 PY-180 180*65 0.3571
HS-32 32*12.7 0.0031 BD-A 100*40 0.08 YN-180 180*72 0.4729
BK-B** 40*9.3 0.0084 HGD-100 100*19.9 0.04134 HC-200 200*60.2 0.3
HL-40 40*44 0.0268 HL-105 105*42 0.0572 HS-200 200*72 0.75
PY-40 45*31.75 0.0172 CX-118 118*61 0.1625 YT-200 200*52.5 0.3935
PY-40 40*31.3 0.0163 DB-A 118*61 0.04754 SQ-A 220*53.5 0.2062
LG-48 48*10 0.0042 QD-118 118*60 0.122 JH-220 220*85 0.9
BMW-50 50*12.7 0.00263 SJ-120 120*61 0.1477 JA-220 220*50.3 0.4
QY-50 50*25 0.01238 RN-120 120*60 0.125 DY-250 250*50.3 0.3507
DG-50* 50*22.225 0.03 WG-123 123*38 0.0703 LP-250 250*50.3 0.523
GF-B 50*19 0.0093 GF-A* 125*19 0.0243 CQ-255 255*72 0.4758
GMD-B 50*20 0.0109 DN-A* 130*18.5 0.0289 FP-250 250*80 0.4897
HGD-52 52*58 0.0474 WJ-130 130*40 0.1088 WD-255 255*73 0.4549
HGD-60 60*19.9 0.02179 TH-136 136*45 0.0868 SQ-B 255*72 0.45
JTDX-60* 60*15.2 0.012 WGJ-130 130*65 0.4348 CF-280 280*60 1.9
XL-60** 60*13.9 0.59 VM-14- 140*20 0.025 PY-280 280*87 0.4839
LWM-60* 60*22.225 0.023 HBC-140 140*30 0.0334 GW-290 290*64.3 0.3409
JQ-B** 60*12.7 0.0182 SL-140 140*80 0.2778 KD-320 320*87 2.1607
PY-60 60*31.428 0.02 JT-140 140*20 0.0332 QATV-320 320*87 0.4688
BF-B** 60*15 0.0073 ZSY-140 140*45 0.13889 WD-320 320*72
BK-A** 60*13.01 0.0178 PW-148 148*60 0.2804 TG-320 320*87 0.9412
DN-B* 60*18.5 0.0088 ZY-148 148*60 0.4445 TJ-360A 360*87 0.8285
JT-60 60*20 0.0125 XF-A 150*59 0.2051 NY-380 380*65 0.7854
JQ-A** 76*12.7 0.0158 NG-150 150*65 0.3095 YQZG-400 400*73
BF-A** 80*15 0.0112 SF-150 150*72 0.3781 NY-380 380*65 0.5326
HL-80 80*44 0.055 HS-150 150*65 0.34783 QATV-400 400*87 1.25
SMX-70 70*40 0.0636 XF-B 150*59 0.2178 TK-560 560*105 3
CHJ-80 80*40.2 0.0817 HD-160 160*61.3   DNS-580 580*60.5 0.675
TH-85 85*59.4 0.08 PY-160 160*60 0.8065 XLG-620 620*100
THG-85 85*59.4 0.1072 YSD-165 165*64.5 0.3612 BV206 620*90.6 3.125
HF-96 96*12.55 0.015 WJ-165 165*65.5 0.2989 WZY-800 800*90.6
GMD-A 100*20 0.0242 WHKD-170 170*64 0.2419 KCM-500 500*110 2.9836
Remark: * means the links must be multiple of 2
  ** means the links must be multiple of 3
