Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm For Kubota Rx202 U20

Certification
China Shanghai Puyi Industrial Co., Ltd. certification
China Shanghai Puyi Industrial Co., Ltd. certification
I'm Online Chat Now

Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm For Kubota Rx202 U20

Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm  For Kubota Rx202 U20
Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm  For Kubota Rx202 U20 Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm  For Kubota Rx202 U20 Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm  For Kubota Rx202 U20

Large Image :  Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm For Kubota Rx202 U20

Product Details:
Place of Origin: SHANGHAI
Brand Name: POOYERT
Certification: ISO9001:2000
Model Number: 250 x 96 x 41
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wood pallet or Container depends on the quantity
Delivery Time: 10-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Pieces per month
Detailed Product Description
Product Name: Rubber Crawler Wide: 250mm
Pitch: 96mm Links: 41
Market: World Color: Black
Technology: Continuous With Joint Free Weight: 89KG
High Light:

undercarriage rubber tracks

,

rubber digger tracks

Rubber tracks Size 250mm x 96mm x 41 for KUBOTA RX202 / KUBOTA U20 / AIRMANN AX20U / BROKK K330





1.Product Information

1.Name of commodity Rubber Track 250 x 96x 41 for mini excavators
2.Width 250mm
3.Pitch 96mm
4.Links 41
5.Total Length 3936mm
6.Weight 89kg
7.Material Rubber & Steel
8.Steel cord type Continuous inner steel cord with joint free
9.Warranty Guarantee one year under normal use






2.Application



Brand Original Size POOYERT Size1 Roller POOYERT Size2 Roller
RX202 (KUBOTA) 250x96x41 250x96x41 B1
U20 (KUBOTA) 250x96x41 250x96x41 B1
AX20U (AIRMANN) 250x96x41 250x96x41 B1
K330 (BROKK) 250x96x41 250x96x41 B1 230x96x41 B1
EX20U (HITACHI) 250x96x41 250x96x41 B1
EX20U.1 (HITACHI) 250x96x41 250x96x41 B1






3.Production process



Raw Material: Natural rubber / SBR rubber/ Kevlar fiber / Metal / Steel cord

Step: 1.Natural rubber and SBR rubber mixed together with special ratio then they will be formed as

rubber block

          2.Steel cord coverd with kevlar fibe

          3.Metal parts will be injected with special compounds which can improve their performance

          3.The rubber block , kevlar fiber cord and metal will be put on the mould in ordered

          4.The mould with materials will be deliver in to the big production machine, the machinery use high

temperature and high volume press to make all the material together.





Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm  For Kubota Rx202 U20 0




4. Packing

The goods will be packed by wrapping film then bundle on the wooden pallet by strong rope in order to make sure the safe transportation.



Low Noise Excavator Rubber Tracks Size 250 X 96 X 41mm  For Kubota Rx202 U20 1


5.Parameter for more size

Width*Pitch length(mm) Number of Links Width*Pitch length(mm) Number of Links Width*Pitch length(mm) Number of Links
130*72 28-53 300*52.5K 72-84 400*72.5KW 68-92
150*60 28-49 300*52.5KW 72-92 400*74 68-76
150*72 29-40 KB300*52.5 72-92 400*75.5K 74
170*60 30-40 KB300*52.5N 72-98 B400*86 52-55
180*60 30-40 JD300*52.5N 72-98 400*90 42-56
180*72 30-58 300*53K 80-84 Y400*142 36-37
180*72K 30-37 300*55 70-86 400*144 36-41
B180*72K 34-51 300*55.5K 76-82 Y400*144K 36-41
B180*72A 30-51 300*71K 72-55 420*100 50-58
H180*72 30-50 300*109N 25-42 450*71 76-88
190*60 30-40 K300*109 37-41 DW450*71 76-88
190*72 34-39 300*109WK 35-42 450*73.5 76-84
200*72 34-47 B300*84 78-52 450*76 80-84
200-*72K 37-47 T300*86K 48-52 450*81N 72-80
230*48 60-84 320*52.5 72-98 450*81W 72-78
230*48K 60-84 B320*52.5 68-98 KB450*81.5 72-80
230*72 42-56 320*54 70-84 K450*83.5 72-74
230*72K 42-56 B320*86 49-52 B450*84 53-56
230*96 30-48 320*90 52-56 B450*86 52-55
230*101 30-36 320*100 38-54 450*90 58-76
250*47K 84 320*100W 37-65 KU450*90 58-76
250*48.5K 80-88 Y320*106K 39-43 T450*100K 48-65
250*52.5K 72-78 350*52.5 70-92 K450*163 38
250*72 47-57 350*54.5K 80-86 485*92W 74
B250*72 34-60 B350*55K 77-98 500*90 76-82
B250*72B 42-58 350*56 80-86 500-92 72-84
E250*72 37-58 350*75.5K 74 500*92W 78-84
250*96 35-38 350*90 42-56 500*100 71
250*109 35-38 350*100 46-60 K500*146 35
260*55.5K 74-80 350*108 40-46 600*100 76-80
Y260*96 38-41 350*109 41-44 600*125 56-64
260*109 35-39 Y370*107K 39-41 700*100 80-98
280*72 45-64 400*72.5N 70-80 750*150 66
Y280*106K 35-42 400*72.5W 68-92 800*125 80
300*52.5N 72-98 Y400*72.5K 72-74

6.Company introduction

Our firm established in 2000, with almost 20 years production and administration experience. With register capital around 2 billion yuan. Through 18 years develop, our company has producted various rubber tracks and related rubber product for our clients. Our goods share with good quality and exported to more than 100 countries and region.
