52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510

Certification
China Shanghai Puyi Industrial Co., Ltd. certification
China Shanghai Puyi Industrial Co., Ltd. certification
I'm Online Chat Now

52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510

52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510
52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510 52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510

Large Image :  52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510

Product Details:
Place of Origin: CHINA
Brand Name: PY
Certification: ISO9001
Model Number: 483X152.4X52
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: negotiable
Packaging Details: Pallet
Delivery Time: 10-15 days
Payment Terms: T/T
Supply Ability: 5000 pcs per month
Detailed Product Description
Width: 483mm Pitch: 152.4
Link: 52 Overall Length: 7924.8mm
Weight: 315.64KG Material: Rubber
High Light:

rubber track belt

,

rubber crawler tracks



Volvo PF5510 Asphalt Paver Rubber Tracks (483mm width and 52 links)





We can ensure the Paver rubber track can be perfictly fit on following models:



1. Blaw Knox PF5510
2. Ingersoll-Rand PF5510
3. Volvo PF5510





Specification:



Applicable machines various kinds of pavers
Material rubber and steel,fiber
Size 483X152.4X52
Installation position Installed on the paver undercarriage
Pattern Smooth pattern



Paver rubber track feature:



There are many types of asphalt paver rubber tracks in the market,but crawler paver has low noise when running,cause less damage to roads than steel tracks, and less rutting of soft ground than either steel tracks of wheel products.A benefit to equipment operating in congested areas and rubber tracks insulate machine and operator from vibration, extending the machine's lifetime and lowering operate fatigue.

The added traction of rubber, track vehicles permits them to pull twice the load of wheel vehicles of the sane weight.Also rubber track permit machines to travel at a higher speed than steel tracks.



Our joint free track structure, Special designed tread pattern, 100% virgin rubber,and one piece forging insert steel result extreme durability & performance and longer service life for construction equipment use. Our tracks perform a high level of reliability and quality with our latest technology in mold tooling and rubber formulation.







Extreme Durability & Performance



For Blowknox PF5510 rubber track,size is 483X152.4X52,also says 19X6X52 or 19X52X6 in inch.

Different number but it's talking with he same rubber track. The number often typed on the tracks body.

If you don't see,you can also measure the track to make sure the size.



483X152.4X52 means width 483mm X pitch 152.4mm X link 52

19X52X6 means width 19" X pitch 6" X link 52

* pitch means the center distance between two inner guide blocks.

* link means the quantity of the inner guide blocks



And for this rubber track,we only have smooth patten as you seen in the ads.



Application



52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510 0



Packing



We use standard shipping pallets, and generally use plywood materials that are not fumigation trays. This material is universal in the world and can be exported directly without fumigation. It is also a widely used advanced packaging material and meets the requirements of relevant national laws and regulations and customer requirements.

Please also advise which sea port we should deliver,then check the deliver time and shipping time.

Any special requirement on packing and delivery,please feel free to contact us.



52 Link Asphalt Paver Rubber Tracks Smooth Pattern For Volvo PF5510 1





WHAT LOGISTICS WAYS WE CAN WORK FOR SHIPMENT?


1. For 90% of our shipment,we will ship by sea,to all main continents such as South America,Middle East,Africa,Oceania and Europe etc...
2. For neighborhood countries of China,such as Russia,Mongolia,Uzbekistan etc,.We can ship construction machinery by road or railway.
3. For light parts in urgent demand,we can ship it by international courier service,such as DHL,TNT,UPS,or FEDEX.
